Products  >  Unified Communications  >  VoIP Gateways, Routers, IADs, and eSBCs  >  ESBC with TDM Ports  >  SmartNode 5570 PRI eSBC

Session Border Controller + Router
SmartNode 5570 eSBC with 1 or 2 T1/E1/PRI Ports

The cost-effective SmartNode 5570 eSBC provides 1 or 2 T1/E1/PRI ports with state-of-the-art security features. Transcoding for up to 16 SIP-to-SIP calls, high-definition G.722 codec, and QoS deliver optimum voice quality over IP.

Contact Us
Sales: sales@patton.com
Direct: +1 301 975 1000
Support: support@patton.com
Direct: +1 301 975 1007
Have Us Contact You
or
Login
 Connect with us
Twitter Linkedin Facebook Youtube

View All

Features

Overview

Applications

Specs

Ordering

Services



Features
  • Supports 30 VoIP calls—1 or 2 ISDN E1/T1 PRI ports. 30 simultaneous G.722, T.38 or G.711 ISDN to VoIP calls. Including SIP TLS and SRTP support for 30 calls.
    Or up to 16 SIP-to-SIP transcoded calls (e.g. G711 to G722 or RTP to SRTP)
  • Full VoIP protocol support—SIPv2, SIPv2 over TLS, ISDN, DSS1, NI-2, QSIG**, T.38, G.722 HD voice, RTP Security with SRTP, fax and modem bypass, DTMF relay. SIP to SIP transcoding for up to 15 calls, non transcoding up to 512**** calls.
  • Full Telephony FeaturesSessionRouter allows flexible call routing and numbering plan adaptations, CLIP/CLIR, hold, transfer, 3-way conferencing (Roadmap) and much more.
  • SIP Registrar - License is included in ALL eSBC products.
  • Complete Access Routing —Two 10/100/1000 Ethernet ports with auto MDI-X. Ethernet Layer 2 switching and bridging. Access router with NAT, Policy Based Routing, Stateful Firewall,PPPoE, DHCP, DynDNS.
  • Management & Provisioning— Web-based management, WEB Wizard, SNMPv3, command line interface, auto-provisioning, separate config domain support, secure provisioning for configuration & software upgrades.
  • Outstanding Interoperability—Interoperable for voice and T.38 fax with leading SIP service providers, softswitch vendors, and Asterisk™ IP-PBX.
  • Class A Compliance—All models with external (EUI) power supply.
  • High Precision Clock (HP) OptionDECT PBX interoperability and improved fax performance with Stratum 3 CO quality clock (HP)***.
  • Supported by SmartNode™ Redirection ServiceA free service enabling zero-touch mass deployments for Service Providers and Distributors with auto-provisioning servers (Learn More).
  • Why SmartNode™?
    • Patton Quality
    • Made in the USA
    • Unrivalled Customer Support
    • FREE Support and Upgrades

Number of Calls :    Default - Ships with Max possible (upgradeable) License SKU
Transcoded SIP to SIP calls 15  15  N/A
SIP to SIP calls (same codecs)  15  256  SNSW-1B
SIP to TDM (PRI)
 15 or 30*  30  SNSW-49V1


*depending on model

Overview
The SmartNode SN5570 Enterprise Session Border Controller + Router bridges a wide range of IP-PBX products to their SIP Trunk service providers. With its built-in Security features such as SIP TLS, SRTP, Stateful Firewall and Secure provisioning, it protects the LAN networks from fraud strikes out of the Internet.

The unique Web Wizard, enables an easy and hassle-free installation, and enables technical people to create their own Web interface.

With the separate config domain feature, the SN5570 will be the service demarcation point for SIP Trunk service providers. Where the local administrator can only modify configuration settings facing the LAN IP PBX.

The SN5570 can also be used to do VoIP call transcoding for up to 16 calls. For instance converting G.722 codecs on the LAN side to G711 on the WAN side.

Like every SmartNode, the SN5570 Series models are state-of-the-art eSBCs that also provide complete policy-based IP routing.

The SmartNode SN5570 is the solution for service providers and network integrators looking for a VoIP product that matches up to ISDN standards in terms of features and quality and solves SIP to SIP interoperability issues.


Applications
Network Integration

Whether used as an Enterprise Session Border Router or as a VoIP gateway/router, the SmartNode 5570 provides excellent VoIP, IP QoS and security features for seamless network integration. All PRI ports are configurable to be TE or NT, you can thus connect your PSTN line as well as an ISDN PRI PBX.For business class IP telephony at the tip of your fingers, the SmartNode SN5570 is more than just talk!

SmartNode 5570


Ordering
Please make sure you order the right amount of SIP sessions to come with the units. See optional sessions that can be loaded upon ordering under accessories.

# Model # Description Availability
1 SN5570/1E30V/EUI SmartNode eSBC, 1 E1/T1 PRI, 30 VoIP Calls, 15 SIP Sessions (SIP b2b UA) upgradeable (max. 256), 16 Transcoded SIP Sessions, SIP-TLS, SRTP, 2x Gig Ethernet, 1x USB port, external UI power (100240 VAC) NA/EU General Availability

 Accessories
2 SN5570/1E30VHP/EUI SmartNode eSBC, 1 E1/T1 PRI, 30 VoIP Calls, 15 SIP Sessions (SIP b2b UA) upgradeable (max. 256), SIP-TLS, SRTP, 16 Transcoded SIP Sessions, High Precision 5ppm Clock, 2x Gig Ethernet, 1x USB port, external UI power (100240 VAC) NA/EU General Availability

 Accessories
3 SN5570/2E30VR/EUI SmartNode eSBC, 2 E1/T1 PRI, 30 VoIP Calls, 15 SIP Sessions (SIP b2b UA) upgradeable (max. 256), SIP-TLS, SRTP, 16 Transcoded SIP Sessions, Fallback Relay, 2x Gig Ethernet, 1x USB port, external UI power (100240 VAC) NA/EU General Availability

 Accessories
4 SN5570/2E30VRHP/EUI SmartNode eSBC, 2 E1/T1 PRI, 30 VoIP Calls not upgradeable, 15 SIP Sessions (SIP b2b UA) upgradeable (max. 256), SIP-TLS, SRTP, 16 Transcoded SIP Sessions, High Precision 5ppm Clock, Fallback Relay, 2x Gig Ethernet, 1x USB port, external UI power NA/EU ( General Availability

 Accessories
