| Patton's Model 2701RC G.703/G.704 Network Termination Unit (NTU) terminates G.703/G.704 lines and provides E1/Fractional E1 |
|
| Features |
Overview |
Applications |
Highlights |
Specs |
Ordering |
Related Info |
|
| |
 - Terminates E1/Fractional E1 service
- Available in low-cost standalone (2701) or rack-mountable versions
- n x 64 kbps data rates to 2 Mbps
- X.21, V.35, EIA-530 and Ethernet bridge options
- Switch-selectable AMI or HDB3 line encoding options
- Switch-selectable DTE/DCE modes for X.21 version
- 75-ohm dual coax and 120-ohm twisted-pair G.703 connections
- Local and remote loopback diagnostics
- Internal, external and G.703 network timing
- CE approval
- Rack cards fit into Model 1001 access rack system
- Conforms to ONP requirements CTR 12 and CTR 13 for connection to international Telecom networks
|
|
|
|
