OnSite™ Model 3200 Series 2Base-TL Ethernet First Mile G.SHDSL Modem

Patton’s OnSite Model 3200 offers the reliability, reach, and rates essential for today’s high speed, broadband Ethernet first-mile services and remote office connectivity.

Contact Us
Sales: sales@patton.com
Direct: +1 301 975 1000
Support: support@patton.com
Direct: +1 301 975 1007
Have Us Contact You
or
Login
 Connect with us
Twitter Linkedin Facebook Youtube

View All

Features

Overview

Applications

Specs

Ordering

Services



Features
--Image: 2010 NGN Leadership --
  • Standards Based G.SHDSL speeds to 22.8 Mbps—Get reliable broadband connectivity with TC-PAM full-duplex symmetric rates and distances exceeding 24,000 feet (7,300 meters).   Additional features allow for line rates up to 60Mbps.
  • EFM—Pure Ethernet solution provides seamless integration into today’s and future networks.
  • MTU Support—1,792 bytes.
  • QoS, CoS, and VLAN Support—Make the most out of your service offerings or ensure top quality network connections with advanced traffic management features.
  • Interoperable with DSLAMs or Point-to-Point—Take advantage of Patton reliability whether you connect back to back or to third-party DSLAMs
  • 4 x 10/100 Ethernet Switch—Make up to 4 network connections easily. Built in MDI-X auto cross over switches eliminates messy and confusing cable configurations.
  • WWW/SNMP Manageable—Built-in VT-100 console port makes setup a snap, and you can use the embedded HTTP/SNMP agent to manage the Model 3200 from anywhere in the world.
Overview
The Patton OnSite™ Model 3200 simplifies and provides cost effective network extension by utilizing pre-existing twisted pair infrastructure enables service providers to offer broadband or data backhaul services to businesses, governments, and various institutions over existing last-mile, copper infrastructure. Today, more than ever, operators are finding the business case for leveraging their existing copper networks to be highly attractive from an ROI and initial investment perspective over fiber roll-outs.

The Model 3200 is Ethernet First Mile (EFM) compliant. EFM—also called pure Ethernet—lowers OPEX and CAPEX by resolving one of the biggest deficiencies in carrier networks, the lack of interworking arrangements among different protocols such as Frame Relay, TDM, ATM, and of course DSL. Using EFM allows for more efficient and trouble-free networking environments. Service providers can concentrate on providing differentiated services instead of concentrating on resolving their latest issue of protocol conversions.

Patton’s 3200 G.SHDSL.bis modem incorporates next-generation SHDSL technology with multi-pair bonding to offer unmatched rate, reach and reliable Ethernet connectivity, providing standards based symmetrical 22.8 Mbps of bandwidth over 4-pair (8-wire) at distances up to 1.8 miles (2.9 km). For point to point connectivity line rates up to 60Mbps can be achieved.  The OnSite 3200 comes standard with a 4-port fast Ethernet switch with full QoS and CoS features. VLAN (802.1q) capabilities include 4 levels of priorities, traffic flow control, and rate control. These traffic management and QoS features enable service providers to provision for differentiated services and/or SLAs.

The OnSite 3200 is a complete, managed, end-to-end system when used either back-to-back or with a 3rd party ipDSLAM. The 3200 is the clear and easy choice for mission-critical networking.

Distance Chart 3200 Series (Per Wire Pair)

DSL Line Rate
26 AWG/0.4mm
24 AWG/0.5mm
22 AWG/0.65mm
N kbps kft km kft km kft km
3 192 21.5 6.6 27.2 8.3 34.8 10.6
4 256 19.5 5.9 24.7 7.5 31.5 9.6
8 512 17.5 5.3 22.1 6.7 28.3 8.6
12 768 16.5 5 20.9 6.4 26.7 8.1
16 1024 16 4.9 20.2 6.2 25.9 7.9
20 1280 15 4.6 19 5.8 24.3 7.4
24 1536 14.5 4.4 18.3 5.6 23.5 7.2
32 2048 13.5 4.1 17.1 5.2 21.8 6.6
36 2304 13 4 16.4 5 21 6.4
60 3840 10 3 12.6 3.8 16.2 4.9
72 4608 9.5 2.9 12 3.7 15.4 4.7
89 5696 8.5 2.6 10.8 3.3 13.8 4.2

Distance Chart Model 3202/4W (4 Wire/2 Pair)

DSL Line Rate
26 AWG/0.4mm
24 AWG/0.5mm
22 AWG/0.65mm
N kbps kft km kft km kft km
6 512 19.5 5.9 24.7 7.5 31.5 9.6
8
512
19.5
5.9
24.7
7.5
31.5
9.6
16
1024
17.5
5.3
22.1
6.7
28.3
8.6
24
1536
16.5
5
20.9
6.4
26.7
8.1
32
2048
16
4.9
20.2
6.2
25.9
7.9
40
2560
15
4.6
19
5.8
24.3
7.4
48
3072
14.5
4.4
18.3
5.6
23.5
7.2
64
4096
13.5
4.1
17.1
5.2
21.8
6.6
72
4608
13
4
16.4
5
21
6.4
120
7680
10
3
12.6
3.8
16.2
4.9
144
9216
9.5
2.9
12
3.7
15.4
4.7
178
11392
8.5
2.6
10.8
3.3
13.8
4.2

Distance Chart Model 3202/8W (8 Wire/4 Pair)

DSL Line Rate
26 AWG/0.4mm
24 AWG/0.5mm
22 AWG/0.65mm
N kbps kft km kft km kft km
12 768 21.5 6.6 27.2 8.3 34.8 10.6
16 1024 19.5 5.9 24.7 7.5 31.5 9.6
32 2048 17.5 5.3 22.1 6.7 28.3 8.6
48 3072 16.5 5 20.9 6.4 26.7 8.1
64 4096 16 4.9 20.2 6.2 25.9 7.9
80 5120 15 4.6 19 5.8 24.3 7.4
96 6144 14.5 4.4 18.3 5.6 23.5 7.2
128 8192 13.5 4.1 17.1 5.2 21.8 6.6
144 9216 13 4 16.4 5 21 6.4
240 15360 10 3 12.6 3.8 16.2 4.9
288 18432 9.5 2.9 12 3.7 15.4 4.7
356 22784 8.5 2.6 10.8 3.3 13.8 4.2




Applications
The Model 3200 G.SHDSL EFM modems are ideal for delivering remote network access for inter-office connectivity. Businesses can take advantage of the already installed copper infrastructure and pass up to 22.8 Mbps of symmetrical data reliably at distances of up to 1.8 miles (2.9 km).

Utilize pre-existing copper infrastructure for mobile backhaul to reduce Last Mile transport costs and to connect to new packet-switched networks.

Model 3200 application diagrams
