Features
 |
It’s no sprint transitioning telecom infrastructure to converged IP. . . it’s a
long run |
|
- 16 to 64 x T1/E1/J1, 1 to 3 DS3, or 1 OC3/STM-1 in a 2U chassis—Highest system density in the market means the lowest cost per port; up to 66% rack and space cost savings
-
512 to 2,048 VoIP channels (field upgradable)—Simple field upgrade by 16 T1/E1 and 512 VoIP channels or 1 DS3 and 672 VoIP channels
-
Increased system up-time—SS7 link redundancy, dual power supply support, field-upgradable components
-
Low operating expense (up to 80% cost savings) significantly improves ROI—Low power consumption (150 W for the SN10200 at full capacity)
-
Connect with confidence to diverse VoIP endpoints and IP fax—Extensive media handling support for wireline, wireless and fax codecs
SmartNode™ Awards
Overview
Service providers are adding VoIP capabilities to their networks, whether to reduce costs when interconnecting with other carriers, to cost-effectively build out their network footprints, or simply to transport voice traffic across their IP backbones. This can be best accomplished using a SmartNode 10200 Series media gateway, that enables the delivery of VoIP services by bridging voice traffic between the public switched telephone network (PSTN)—based on time-division multiplexing (TDM)—and IP networks such as the Internet. Whether sitting at the network core or at the edge, SmartNode media gateways enable service providers to introduce VoIP into their networks while maintaining the quality and the reliability of traditional TDM networks.
TDM interfaces
Service providers, whether providing local, long-distance or international voice services, are interconnected with a multitude of other providers using T1/E1/J1, DS3 or STM-1 links. It is critical for service providers to be able to rapidly establish new interconnections without having to always deploy new devices. SmartNode 10200 Series media gateways therefore offer flexibility and can be configured to support T1/E1/J1, DS-3 or STM-1 interfaces.
Signaling and control protocols
Just as flexibility in the selection and deployment of TDM links is a key requirement for service providers, the need to support multiple signaling protocols across various carrier partners is just as important. Each SN10200 media gateway provides support for the concurrent use of ISDN, SS7/C7, CAS (R2), SIP, and SIGTRAN signaling in the same device. The ability to provide both switching and conversion across multiple TDM and IP signaling protocols at once is paramount to enabling the operational flexibility and cost savings that drive service providers to expand their carrier relationships and converge their networks.
In parallel with the TDM and IP signaling protocols mentioned above, SN10200 devices also support the H.248 media gateway control protocol, which enables any H.248-compliant 3-party softswitch to control a media gateway. While the softswitch manages call control interactions, the SN10200 handles transmission of call media as well as any required transcoding.
Media handling
Service providers will use one or more codecs on their VoIP networks according to their desire to save bandwidth, to provide a certain level of voice quality, or simply to interoperate with other VoIP devices or providers. The ability to support multiple different concurrent codecs and to allocate them in real time based on traffic is the key to delivering true network convergence.
SmartNode 10200 gateways feature extensive support for various wireline, mobile and IP telephony audio formats, delivering seamless transcoding in real-time. The media gateways ship with support for G.711, G723.1, G.726, and G.729ab right out of the box, with no additional license fee required. They also offer optional support for mobile and IP vocoders such as AMR, AMR-WB (G.722.2), GSM-FR/GSM-EFR, EVRC/QCELP, G.728, G.729eg, and iLBC. SN10200 gateways offer independent dynamic codec selection per channel. This means that it is possible to assign different vocoders to different channels, on a channel-by-channel basis. The devices can then run all of these codecs concurrently and do so with no impact on system performance.
SN10200 gateways also provide unparalleled support for Internet-based fax, also known as Fax over IP or Fax relay, using the T.38 protocol, which is used to carry fax communications over an IP network. (They also support the T.30 protocol for fax over the PSTN.)
System density
SN10200 gateways feature the industry’s highest system density in a 2U form factor. Beside the capital savings achieved by purchasing less units of equipment, system density also provides operational cost savings in the form of reduced co-location fees as well as lower power and cooling costs.
Energy efficiency
For many, if not most, service providers, the payoff from reducing energy use can be particularly impressive; typically, for every watt of power required to operate a device, another watt is required to cool it. The SN10200 media gateways can play a major role in reducing energy costs, with an average two-thirds less power consumption than competing products of similar capacity.
Provisioning and maintenance
For network convergence efforts to contribute positively to revenue and profitability, service providers must maintain their reputation for uptime and availability during the introduction, operation, and maintenance of new services. The SN10200 offers OAM&P, an operations, administration, maintenance, provisioning (OAM&P) solution. OAM&P enables the service provider to perform the initial set-up of the SN10200 media gateway and any subsequent maintenance operations. These range from the simple, such as the collection of statistics and alarms, to the more complex, such as system configuration changes, the addition of new hardware or software components, and the application of software patches or software upgrades.
Applications
Enterprise Applications
Business Trunking Solutions
Softswitch compatible media gateways enable SIP Trunking services, providing a secure point of demarcation for the carrier and allowing subscribers to utilize existing TDM equipment including PBXs, IVR systems, Call Centers or other legacy equipment without expensive upgrades. High call density Media Gateways are needed for large Enterprises and Call Centers.
Call Centers
The legacy Call Center has gone through a metamorphosis, emerging as the IP Call Center which replaces the PBX and separate IVR and ACD systems and merges email and instant messaging into a new architecture that integrates these functions leveraging Voice over IP technologies. With IP Call Centers, full-featured Call Centers can be deployed with agents virtually anywhere globally where there is IP connectivity. IP Call Centers reduce costs leveraging inexpensive overseas labor or working at home agents (WAHA) and provide tremendous flexibility to adapt to changing markets and labor resources.
High-density gateways and SS7 signaling support are important for large enterprise Call Centers, either for large scale integration of legacy PSTN networks to IP-based Call Center applications or VoIP integration to legacy Call Center platforms.
Transcoding for the Enterprise
Wireline and wireless carriers now deliver high-quality internet telephony services over a range of customer-provided last-mile technologies including cable, ADSL, E1/T1 and RF facilities. Many of these services depend on using low bit rate coders to compress voice and improve network efficiency, especially to cross the last mile connection to their ISP. The range of voice coding algorithms has caused a huge interoperability challenge for integrators that are attempting to interface solutions from various vendors. Transcoding the voice from one format to another in real-time, with high quality and low-latency is a significant challenge. SmartNode transcoding offers the capability to mediate between these protocols and signaling.
Carrier Applications
High Traffic CPE for the Enterprise
The SmartNode 10200 can be used as a Carrier CPE providing SIP Trunks to large corporation with large legacy PBX, outsourcing Call Center with overseas operations, large legacy-based Call Centers, IP migration for large Call Centers or large Enterprises.
Carrier Core
The SmartNode 10200 is used on the Carrier core providing:
- Wholesale origination and termination (i.e. calling cards)
- Local, long distance and ILD carrier interconnection
- Transcoding and IP to IP normalization
- High definition voice transport
- Fax over IP
- LCR (least cost routing)
Carrier IP Migration
The SmartNode 10200 is usedfor IP integration in the core network (SS7 to SIGTRAN) as well as legacy central office integration to IP infrastructure.
IP Migration Carrier Edge
IP Migration Carrier
Core
Value Added Services (Third Party Apps integration or Development)
Service providers are now building value-added services with all IP-based elements, typically using the SIP protocol, and in fewer cases using other IP protocols as the legacy H.323. These emerging IP-based networks offer enormous potential for generating new services and increasing revenue per subscriber, but the introduction of IP throughout the network also creates challenges. For all-IP environments, new elements are required that can mediate signaling, transcode among different media formats, and handle basic security issues.
- Audio streaming applications (ex: ring back tones, background noise/music injection, etc.)
- Interactive voice response (IVR)-based applications (ex: virtual assistant, follow me, call back, sponsoring ads, etc.)
- IP roaming for mobile.
- Social network integration
- Temporary numbers to hide identity
- Hosted conferencing
Specifications
| Capacity and voice processing |
VoIP channels—512 to 2,016
PSTN interfaces—1 OC3/STM1 with APS (automatic protection switching) • 1 to 3 DS3 • Dual RJ48C for BITS or T1/E1 for signaling
VoIP interfaces—Dual 100/1000Base-T • RJ45 connectors on rear of unit
Vocoding—Universal codecs: G.711, G.723.1, G.726, G.729ab, T.38 • Other codecs: G.722.2 (AMR-WB), G.728, G.729eg, iLBC, clear mode (RFC 4040)
Fax/Modem/Data—T.38 fax relay (V.17 and V.34) • Automatic G.711 fallback • Modem and data pass-through
DTMF relay—RFC 2833, SIP INFO Method, In-band
Echo cancellation—G.168 echo cancellation • 128 ms echo tail on all channels simultaneously
Voice processing—Dynamic and programmable jitter buffer (20 to 200 ms) • Voice activity detection (VAD) • Comfort noise generation (CNG)
Management interfaces—Dual 100/1000Base-T for OAM&P |
| Simultaneous signaling support |
SIP—Supported RFCs: 2327, 2976, 3261, 3262, 3263, 3264, 3311*, 3323*, 3325*, 3398, 3515*, 3578*, 3764, 3891, 4028 (*partial compliance)
SIGTRAN—M2PA, M2UA, M3UA, IUA • SS7 termination and/or relay supported
SS7—Up to 64 x MTP2 links (56, 64, n x 56/64 kbps, HSL) • Multiple redundant MTP2 links • Up to 64 MTP3 originating point codes and linksets • ISUP variants: ITU 92, ITU 97, ANSI 88, ANSI 92, ANSI 95, Telcordia 97, ETSIv2, ETSIv3, China, Singapore, UK Brazil
ISDN PRI—Q.931 ISDN PRI: NI-2, 4ESS, 5ESS, DMS-100, DMS-250, Euro ISDN ETSI NET5 (France, Germany, UK, China, Hong Kong, Korea), NTT (Japan), Australia
CAS—MFC R2 (standard ITU, Brazil) • Customizable protocol script files |
| SmartNode-CONTROL |
Standalone call control—Any to any call routing (TDM-VoIP, TDM-TDM, VoIP-VoIP with transcoding) • Call routing based on: trunk group, calling/called numbers, nature of address, ASR, time of day, load-based, cost-based, TO:, FROM: Request URI, redirect numbers, and other parameters • NPA-NXX routing (100k+ table entries, Excel or CVS file upload) • Route retries • Call transfer (REFER, AT&T TR 50075)
H.248 (MEGACO) call control—ITU-T H.248 versions 1 and 2 • UDP, SCTP, IPsec transport • DTMF and fax detection • DTMF, announcements and call progress tone generation • Call quality and inactivity alerts
Session management and billing—SIP peer availability polling • RTP inactivity monitoring • CDR generation (RADIUS and text file) |
| OAM&P |
Operation & Administration—Web-based system status and operations • SNMP v2/v3 GET, TRAPs and alarms • Dynamic configuration changes
Maintenance—Web-based interface for maintenance • Automated system upgrade • System backup, restore and copy
Provisioning—Web-based interface for configuration • Dynamic activation
Troubleshooting—Per-call tracing (history and/or live) • Signalling capture tools • SSH command-line interface) |
| Electrical characteristics |
Power input—90 to 260 VAC, 47 to 63 Hz • -40 to -60 VDC • Redundant power supply with dual power inputs • Maximum 138 W power consumption |
| Physical characteristics |
Dimensions—2U, 3.5H x 17.4W x 16D in. (88.9H x 442W x 406D mm)
Weight—20 lbs (9.1 kg) |
| Regulatory compliance |
UL/CSA 60950, CSA C22.2—EMC: FCC Part 15:2009, Subpart B, CE Mark (EN55022:2006, Class A, EM60950, EN61000, ETS 300 386) |
| Environmental |
Operating temp: 0 to +55 °C, 95% relative humidity, non-condensing
Storage temp: -10 to +75 °C, 95% relative humidity, non-condensing
NEBS Level 3 compliant
RoHS compliant |
Ordering Information
| Model # |
Description |
| SN10020/16SE/RUI |
SmartNode SmartMedia TDM Switch 16E1/T1 Span with Standard Signaling Set. Redundent Universal AC Power |
| SN10020/24SE/RUI |
SmartNode SmartMedia TDM Switch 24E1/T1 Span with Standard Signaling Set. Redundent Universal AC Power |
| SN10020/32SE/RUI |
SmartNode SmartMedia TDM Switch 32E1/T1 Span with Standard Signaling Set. Redundent Universal AC Power |
| SN10020/8SE/RUI |
SmartNode SmartMedia TDM Switch 8E1/T1 Span with Standard Signaling Set. Redundent Universal AC Power |
| SN10200/16E/R48 |
SmartNode SmartMedia Gateway 16 E1/T1, 512 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/16E/RUI |
SmartNode SmartMedia Gateway 16 E1/T1, 512 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/16EBU/RUI |
SmartNode SmartMedia Gateway 16 E1/T1, 512 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power (1+1) |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1plus-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/1DS3/R48 |
SmartNode SmartMedia Gateway 1 DS3, 672 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/1DS3/RUI |
SmartNode SmartMedia Gateway 1 DS3, 672 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/2DS3/R48 |
SmartNode SmartMedia Gateway 2 DS3, 1344 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/2DS3/RUI |
SmartNode SmartMedia Gateway 2 DS3, 1344 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/2DS3BU/RUI |
SmartNode SmartMedia Gateway 2 DS3, 1344 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1plus-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/32E/R48 |
SmartNode SmartMedia Gateway 32 E1/T1, 1024 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/32E/RUI |
SmartNode SmartMedia Gateway 32 E1/T1, 1024 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/3DS3/R48 |
SmartNode SmartMedia Gateway 3 DS3, 2016 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/3DS3/RUI |
SmartNode SmartMedia Gateway 3 DS3, 2016 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/48E/R48 |
SmartNode SmartMedia Gateway 48 E1/T1, 1536 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/48E/RUI |
SmartNode SmartMedia Gateway 48 E1/T1, 1536 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/64E/R48 |
SmartNode SmartMedia Gateway 64 E1/T1, 2048 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/64E/RUI |
SmartNode SmartMedia Gateway 64 E1/T1, 2048 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/STM1/R48 |
SmartNode SmartMedia Gateway 1 OC3/STM-1, 2016 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/STM1/RUI |
SmartNode SmartMedia Gateway 1 OC3/STM-1, 2016 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
|
Support Services
| Item Number |
Item Description |
Price |
| SVC-P-7x24-L |
Premium Support with guaranteed response and remedy times 24x7. See your sales rep for details. Annual Subscription over 10,000 units deployed. |
Contact us for availability and pricing. |
| SVC-P-7x24-M |
Premium Support with guaranteed response and remedy times 24x7. See your sales rep for details. Annual Subscription 1,000 to 10,000 units deployed. |
Contact us for availability and pricing. |
| SVC-P-7x24-S |
Premium Support with guaranteed response and remedy times 24x7. See your sales rep for details. Annual Subscription up to 1,000 units deployed. |
Contact us for availability and pricing. |
| SVC-P-SH-L |
Premium Support with guaranteed response and remedy times for regional business hours support Mo-Fr. See your sales rep for details. Annual Subscription over 10,000 units deployed. |
Contact us for availability and pricing. |
| SVC-P-SH-M |
Premium Support with guaranteed response and remedy times for regional business hours support Mo-Fr. See your sales rep for details. Annual Subscription 1,000 to 10,000 units deployed. |
Contact us for availability and pricing. |
| SVC-P-SH-S |
Premium Support with guaranteed response and remedy times for regional business hours support Mo-Fr. See your sales rep for details. Annual Subscription up to 1,000 units deployed. |
Contact us for availability and pricing. |
| SVC-ENHWAR1 |
1 Year Enhanced Warranty |
Contact us for availability and pricing. |
| SVC-ENHWAR2 |
2 Year Enhanced Warranty |
Contact us for availability and pricing. |
| SVC-ENHWAR3 |
3 Year Enhanced Warranty |
Contact us for availability and pricing. |
| SVC-ENHWAR4 |
4 Year Enhanced Warranty |
Contact us for availability and pricing. |
| SVC-ENHWAR5 |
5 Year Enhanced Warranty |
Contact us for availability and pricing. |
| SVC-EXTWAR2 |
2 Year Extended Warranty |
Contact us for availability and pricing. |
| SVC-EXTWAR3 |
3 Year Extended Warranty |
Contact us for availability and pricing. |
| SVC-EXTWAR4 |
4 Year Extended Warranty |
Contact us for availability and pricing. |
| SVC-EXTWAR5 |
5 Year Extended Warranty |
Contact us for availability and pricing. |
| SVC-TECH-HOUR |
Network technician hour rate for Pre-config services, after hours support etc? |
Contact us for availability and pricing. |
| Related Products |
| VoIP Gateways |
| SmartNode™ 4940 |
Multi-Port T1/E1/PRI Enterprise VoIP Gateway |
| Gateway-Routers |
| SmartNode™ 4950 |
T1/E1/PRI VoIP Enterprise Gateway-Router |
| ESBR |
| SmartNode™ 4960 |
Multi-Port T1/E1/PRI VoIP Enterprise Session Border Router |
Articles (PDF) -- Requires Adobe Acrobat to view |
| How Patton and Techlan Reti Transported Norbert Dentressangle to Converged IP-Communication |
May 07, 2012 |
Certifications (PDF) -- Requires Adobe Acrobat to view |
| Declaration of Conformity - SmartNode 10200/x/Ry |
December 31, 2012 |
Data Sheets (PDF) -- Requires Adobe Acrobat to view |
| SmartNode 10200 Series Datasheet |
March 02, 2012 |
| SmartNode 10200 Series Datasheet (A4 page size) |
March 02, 2012 |
Manuals (PDF) -- Requires Adobe Acrobat to view |
| SmartNode Redirection Server Guide, Administrator's Reference |
July 12, 2012 |
| SmartNode 10200 Series Guide, Quick Start |
May 07, 2012 |
| SmartNode 10200 Series User Manual |
April 03, 2012 |
| Smart Media System Software Configuration Guide |
January 12, 2012 |
News Releases |
| Patton Announces General Availability of Fiber-Optic SmartNode VoIP Gateway Router IADs |
March 19, 2013 |
| Patton Ships SmartNode VoIP IADs with ADSL Interface |
March 12, 2013 |
| Advice of Charge Service Leverages Patton VoIP Gateways |
February 26, 2013 |
| Patton Exhibits Revenue-Enabling Technologies at Mobile World Congress This Week |
February 25, 2013 |
| Mobile World Congress : Patton présentera deux nouvelles gammes de produits destinés à la mobilité d’entreprise |
February 04, 2013 |
| Patton and TMC Launch Microsoft Lync Solutions News Community |
January 30, 2013 |
| Patton Will Present Wireless Bandwidth-on-Demand Internet Routers and Carrier-Grade VoIP Solutions at Mobile World Congress |
January 24, 2013 |
| Patton and RUN Communications Team Up to Offer Canada VoIP Gateways that Just Work |
January 11, 2013 |
| SmartNode Gateways Cited Among Top Ten VoIP Products for 2012 |
January 08, 2013 |
| Llegan los Gateways VoIP de Patton para comunicaciones SIP listos para el futuro de Internet |
December 18, 2012 |
| Get VoIP Service in Just 6 Minutes from VoIP Supply with the New SIP Enable by Patton and Vitelity |
December 07, 2012 |
| Patton Fills VoIP-Market Gap with SmartNode BRI/FXS/FXO Gateway-Router |
March 07, 2012 |
| Patton Ships Thousands of SmartNode BRI VoIP Gateways, New Model Coming Soon. . . |
February 16, 2012 |
| Patton Unveils High-Density Carrier-Grade VoIP Media Gateway Today at ITEXPO |
February 01, 2012 |
| Patton Scores Seven in a Row: SmartNode™ Wins Internet Telephony’s 2011 “Product of the Year” |
January 26, 2012 |
Product/Solutions Guides (PDF) -- Requires Adobe Acrobat to view |
| 3CX IP Solutions Overview |
January 23, 2013 |
| IP Paging/Intercom/Access Control with Microsoft Lync Solution Overview |
December 18, 2012 |
| The Gateway to Microsoft Lync |
December 18, 2012 |
| SmartNode Product Line Overview |
December 18, 2012 |
| The Gateway to BroadWorks |
October 12, 2012 |
|
It’s no sprint transitioning telecom infrastructure to converged IP. . . it’s a
long run |
|
- 16 to 64 x T1/E1/J1, 1 to 3 DS3, or 1 OC3/STM-1 in a 2U chassis—Highest system density in the market means the lowest cost per port; up to 66% rack and space cost savings
-
512 to 2,048 VoIP channels (field upgradable)—Simple field upgrade by 16 T1/E1 and 512 VoIP channels or 1 DS3 and 672 VoIP channels
-
Increased system up-time—SS7 link redundancy, dual power supply support, field-upgradable components
-
Low operating expense (up to 80% cost savings) significantly improves ROI—Low power consumption (150 W for the SN10200 at full capacity)
-
Connect with confidence to diverse VoIP endpoints and IP fax—Extensive media handling support for wireline, wireless and fax codecs
SmartNode™ Awards
Service providers are adding VoIP capabilities to their networks, whether to reduce costs when interconnecting with other carriers, to cost-effectively build out their network footprints, or simply to transport voice traffic across their IP backbones. This can be best accomplished using a SmartNode 10200 Series media gateway, that enables the delivery of VoIP services by bridging voice traffic between the public switched telephone network (PSTN)—based on time-division multiplexing (TDM)—and IP networks such as the Internet. Whether sitting at the network core or at the edge, SmartNode media gateways enable service providers to introduce VoIP into their networks while maintaining the quality and the reliability of traditional TDM networks.
TDM interfaces
Service providers, whether providing local, long-distance or international voice services, are interconnected with a multitude of other providers using T1/E1/J1, DS3 or STM-1 links. It is critical for service providers to be able to rapidly establish new interconnections without having to always deploy new devices. SmartNode 10200 Series media gateways therefore offer flexibility and can be configured to support T1/E1/J1, DS-3 or STM-1 interfaces.
Signaling and control protocols
Just as flexibility in the selection and deployment of TDM links is a key requirement for service providers, the need to support multiple signaling protocols across various carrier partners is just as important. Each SN10200 media gateway provides support for the concurrent use of ISDN, SS7/C7, CAS (R2), SIP, and SIGTRAN signaling in the same device. The ability to provide both switching and conversion across multiple TDM and IP signaling protocols at once is paramount to enabling the operational flexibility and cost savings that drive service providers to expand their carrier relationships and converge their networks.
In parallel with the TDM and IP signaling protocols mentioned above, SN10200 devices also support the H.248 media gateway control protocol, which enables any H.248-compliant 3-party softswitch to control a media gateway. While the softswitch manages call control interactions, the SN10200 handles transmission of call media as well as any required transcoding.
Media handling
Service providers will use one or more codecs on their VoIP networks according to their desire to save bandwidth, to provide a certain level of voice quality, or simply to interoperate with other VoIP devices or providers. The ability to support multiple different concurrent codecs and to allocate them in real time based on traffic is the key to delivering true network convergence.
SmartNode 10200 gateways feature extensive support for various wireline, mobile and IP telephony audio formats, delivering seamless transcoding in real-time. The media gateways ship with support for G.711, G723.1, G.726, and G.729ab right out of the box, with no additional license fee required. They also offer optional support for mobile and IP vocoders such as AMR, AMR-WB (G.722.2), GSM-FR/GSM-EFR, EVRC/QCELP, G.728, G.729eg, and iLBC. SN10200 gateways offer independent dynamic codec selection per channel. This means that it is possible to assign different vocoders to different channels, on a channel-by-channel basis. The devices can then run all of these codecs concurrently and do so with no impact on system performance.
SN10200 gateways also provide unparalleled support for Internet-based fax, also known as Fax over IP or Fax relay, using the T.38 protocol, which is used to carry fax communications over an IP network. (They also support the T.30 protocol for fax over the PSTN.)
System density
SN10200 gateways feature the industry’s highest system density in a 2U form factor. Beside the capital savings achieved by purchasing less units of equipment, system density also provides operational cost savings in the form of reduced co-location fees as well as lower power and cooling costs.
Energy efficiency
For many, if not most, service providers, the payoff from reducing energy use can be particularly impressive; typically, for every watt of power required to operate a device, another watt is required to cool it. The SN10200 media gateways can play a major role in reducing energy costs, with an average two-thirds less power consumption than competing products of similar capacity.
Provisioning and maintenance
For network convergence efforts to contribute positively to revenue and profitability, service providers must maintain their reputation for uptime and availability during the introduction, operation, and maintenance of new services. The SN10200 offers OAM&P, an operations, administration, maintenance, provisioning (OAM&P) solution. OAM&P enables the service provider to perform the initial set-up of the SN10200 media gateway and any subsequent maintenance operations. These range from the simple, such as the collection of statistics and alarms, to the more complex, such as system configuration changes, the addition of new hardware or software components, and the application of software patches or software upgrades.
Enterprise Applications
Business Trunking Solutions
Softswitch compatible media gateways enable SIP Trunking services, providing a secure point of demarcation for the carrier and allowing subscribers to utilize existing TDM equipment including PBXs, IVR systems, Call Centers or other legacy equipment without expensive upgrades. High call density Media Gateways are needed for large Enterprises and Call Centers.
Call Centers
The legacy Call Center has gone through a metamorphosis, emerging as the IP Call Center which replaces the PBX and separate IVR and ACD systems and merges email and instant messaging into a new architecture that integrates these functions leveraging Voice over IP technologies. With IP Call Centers, full-featured Call Centers can be deployed with agents virtually anywhere globally where there is IP connectivity. IP Call Centers reduce costs leveraging inexpensive overseas labor or working at home agents (WAHA) and provide tremendous flexibility to adapt to changing markets and labor resources.
High-density gateways and SS7 signaling support are important for large enterprise Call Centers, either for large scale integration of legacy PSTN networks to IP-based Call Center applications or VoIP integration to legacy Call Center platforms.
Transcoding for the Enterprise
Wireline and wireless carriers now deliver high-quality internet telephony services over a range of customer-provided last-mile technologies including cable, ADSL, E1/T1 and RF facilities. Many of these services depend on using low bit rate coders to compress voice and improve network efficiency, especially to cross the last mile connection to their ISP. The range of voice coding algorithms has caused a huge interoperability challenge for integrators that are attempting to interface solutions from various vendors. Transcoding the voice from one format to another in real-time, with high quality and low-latency is a significant challenge. SmartNode transcoding offers the capability to mediate between these protocols and signaling.
Carrier Applications
High Traffic CPE for the Enterprise
The SmartNode 10200 can be used as a Carrier CPE providing SIP Trunks to large corporation with large legacy PBX, outsourcing Call Center with overseas operations, large legacy-based Call Centers, IP migration for large Call Centers or large Enterprises.
Carrier Core
The SmartNode 10200 is used on the Carrier core providing:
- Wholesale origination and termination (i.e. calling cards)
- Local, long distance and ILD carrier interconnection
- Transcoding and IP to IP normalization
- High definition voice transport
- Fax over IP
- LCR (least cost routing)
Carrier IP Migration
The SmartNode 10200 is usedfor IP integration in the core network (SS7 to SIGTRAN) as well as legacy central office integration to IP infrastructure.
IP Migration Carrier Edge
IP Migration Carrier
Core
Value Added Services (Third Party Apps integration or Development)
Service providers are now building value-added services with all IP-based elements, typically using the SIP protocol, and in fewer cases using other IP protocols as the legacy H.323. These emerging IP-based networks offer enormous potential for generating new services and increasing revenue per subscriber, but the introduction of IP throughout the network also creates challenges. For all-IP environments, new elements are required that can mediate signaling, transcode among different media formats, and handle basic security issues.
- Audio streaming applications (ex: ring back tones, background noise/music injection, etc.)
- Interactive voice response (IVR)-based applications (ex: virtual assistant, follow me, call back, sponsoring ads, etc.)
- IP roaming for mobile.
- Social network integration
- Temporary numbers to hide identity
- Hosted conferencing
| Capacity and voice processing |
VoIP channels—512 to 2,016
PSTN interfaces—1 OC3/STM1 with APS (automatic protection switching) • 1 to 3 DS3 • Dual RJ48C for BITS or T1/E1 for signaling
VoIP interfaces—Dual 100/1000Base-T • RJ45 connectors on rear of unit
Vocoding—Universal codecs: G.711, G.723.1, G.726, G.729ab, T.38 • Other codecs: G.722.2 (AMR-WB), G.728, G.729eg, iLBC, clear mode (RFC 4040)
Fax/Modem/Data—T.38 fax relay (V.17 and V.34) • Automatic G.711 fallback • Modem and data pass-through
DTMF relay—RFC 2833, SIP INFO Method, In-band
Echo cancellation—G.168 echo cancellation • 128 ms echo tail on all channels simultaneously
Voice processing—Dynamic and programmable jitter buffer (20 to 200 ms) • Voice activity detection (VAD) • Comfort noise generation (CNG)
Management interfaces—Dual 100/1000Base-T for OAM&P |
| Simultaneous signaling support |
SIP—Supported RFCs: 2327, 2976, 3261, 3262, 3263, 3264, 3311*, 3323*, 3325*, 3398, 3515*, 3578*, 3764, 3891, 4028 (*partial compliance)
SIGTRAN—M2PA, M2UA, M3UA, IUA • SS7 termination and/or relay supported
SS7—Up to 64 x MTP2 links (56, 64, n x 56/64 kbps, HSL) • Multiple redundant MTP2 links • Up to 64 MTP3 originating point codes and linksets • ISUP variants: ITU 92, ITU 97, ANSI 88, ANSI 92, ANSI 95, Telcordia 97, ETSIv2, ETSIv3, China, Singapore, UK Brazil
ISDN PRI—Q.931 ISDN PRI: NI-2, 4ESS, 5ESS, DMS-100, DMS-250, Euro ISDN ETSI NET5 (France, Germany, UK, China, Hong Kong, Korea), NTT (Japan), Australia
CAS—MFC R2 (standard ITU, Brazil) • Customizable protocol script files |
| SmartNode-CONTROL |
Standalone call control—Any to any call routing (TDM-VoIP, TDM-TDM, VoIP-VoIP with transcoding) • Call routing based on: trunk group, calling/called numbers, nature of address, ASR, time of day, load-based, cost-based, TO:, FROM: Request URI, redirect numbers, and other parameters • NPA-NXX routing (100k+ table entries, Excel or CVS file upload) • Route retries • Call transfer (REFER, AT&T TR 50075)
H.248 (MEGACO) call control—ITU-T H.248 versions 1 and 2 • UDP, SCTP, IPsec transport • DTMF and fax detection • DTMF, announcements and call progress tone generation • Call quality and inactivity alerts
Session management and billing—SIP peer availability polling • RTP inactivity monitoring • CDR generation (RADIUS and text file) |
| OAM&P |
Operation & Administration—Web-based system status and operations • SNMP v2/v3 GET, TRAPs and alarms • Dynamic configuration changes
Maintenance—Web-based interface for maintenance • Automated system upgrade • System backup, restore and copy
Provisioning—Web-based interface for configuration • Dynamic activation
Troubleshooting—Per-call tracing (history and/or live) • Signalling capture tools • SSH command-line interface) |
| Electrical characteristics |
Power input—90 to 260 VAC, 47 to 63 Hz • -40 to -60 VDC • Redundant power supply with dual power inputs • Maximum 138 W power consumption |
| Physical characteristics |
Dimensions—2U, 3.5H x 17.4W x 16D in. (88.9H x 442W x 406D mm)
Weight—20 lbs (9.1 kg) |
| Regulatory compliance |
UL/CSA 60950, CSA C22.2—EMC: FCC Part 15:2009, Subpart B, CE Mark (EN55022:2006, Class A, EM60950, EN61000, ETS 300 386) |
| Environmental |
Operating temp: 0 to +55 °C, 95% relative humidity, non-condensing
Storage temp: -10 to +75 °C, 95% relative humidity, non-condensing
NEBS Level 3 compliant
RoHS compliant |
| Model # |
Description |
| SN10020/16SE/RUI |
SmartNode SmartMedia TDM Switch 16E1/T1 Span with Standard Signaling Set. Redundent Universal AC Power |
| SN10020/24SE/RUI |
SmartNode SmartMedia TDM Switch 24E1/T1 Span with Standard Signaling Set. Redundent Universal AC Power |
| SN10020/32SE/RUI |
SmartNode SmartMedia TDM Switch 32E1/T1 Span with Standard Signaling Set. Redundent Universal AC Power |
| SN10020/8SE/RUI |
SmartNode SmartMedia TDM Switch 8E1/T1 Span with Standard Signaling Set. Redundent Universal AC Power |
| SN10200/16E/R48 |
SmartNode SmartMedia Gateway 16 E1/T1, 512 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/16E/RUI |
SmartNode SmartMedia Gateway 16 E1/T1, 512 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/16EBU/RUI |
SmartNode SmartMedia Gateway 16 E1/T1, 512 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power (1+1) |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1plus-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/1DS3/R48 |
SmartNode SmartMedia Gateway 1 DS3, 672 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/1DS3/RUI |
SmartNode SmartMedia Gateway 1 DS3, 672 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/2DS3/R48 |
SmartNode SmartMedia Gateway 2 DS3, 1344 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/2DS3/RUI |
SmartNode SmartMedia Gateway 2 DS3, 1344 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/2DS3BU/RUI |
SmartNode SmartMedia Gateway 2 DS3, 1344 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1plus-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/32E/R48 |
SmartNode SmartMedia Gateway 32 E1/T1, 1024 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/32E/RUI |
SmartNode SmartMedia Gateway 32 E1/T1, 1024 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/3DS3/R48 |
SmartNode SmartMedia Gateway 3 DS3, 2016 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/3DS3/RUI |
SmartNode SmartMedia Gateway 3 DS3, 2016 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/48E/R48 |
SmartNode SmartMedia Gateway 48 E1/T1, 1536 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/48E/RUI |
SmartNode SmartMedia Gateway 48 E1/T1, 1536 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/64E/R48 |
SmartNode SmartMedia Gateway 64 E1/T1, 2048 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/64E/RUI |
SmartNode SmartMedia Gateway 64 E1/T1, 2048 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/STM1/R48 |
SmartNode SmartMedia Gateway 1 OC3/STM-1, 2016 VoIP Channels with Standard Signaling Set. Redundent -48V DC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
| SN10200/STM1/RUI |
SmartNode SmartMedia Gateway 1 OC3/STM-1, 2016 VoIP Channels with Standard Signaling Set. Redundent Universal AC Power |
| |
| Accessories |
| SNSW-16-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 16-Link License |
| SNSW-1PLUS-SS7-1 |
SmartNode SmartMedia (SN10K models only) Single Link MTP2, MTP3, ISUP License Upgrade |
| SNSW-1-SS7 |
Single Link SS7 MTP2, MTP3, ISUP License |
| SNSW-2-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 2-Link License |
| SNSW-32-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 32-Link License |
| SNSW-4-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 4-Link License |
| SNSW-64-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 64-Link License |
| SNSW-8-SS7 |
SmartNode SmartMedia (SN10K models only) SS7 MTP2, MTP3, ISUP 8-Link License |
| SNSW-M2PA-SIGTRAN |
SmartNode SmartMedia (SN10K models only) SIGTRAN Termination License for M2PA |
|
|
| Item Number |
Item Description |
Price |
| SVC-P-7x24-L |
Premium Support with guaranteed response and remedy times 24x7. See your sales rep for details. Annual Subscription over 10,000 units deployed. |
Contact us for availability and pricing. |
| SVC-P-7x24-M |
Premium Support with guaranteed response and remedy times 24x7. See your sales rep for details. Annual Subscription 1,000 to 10,000 units deployed. |
Contact us for availability and pricing. |
| SVC-P-7x24-S |
Premium Support with guaranteed response and remedy times 24x7. See your sales rep for details. Annual Subscription up to 1,000 units deployed. |
Contact us for availability and pricing. |
| SVC-P-SH-L |
Premium Support with guaranteed response and remedy times for regional business hours support Mo-Fr. See your sales rep for details. Annual Subscription over 10,000 units deployed. |
Contact us for availability and pricing. |
| SVC-P-SH-M |
Premium Support with guaranteed response and remedy times for regional business hours support Mo-Fr. See your sales rep for details. Annual Subscription 1,000 to 10,000 units deployed. |
Contact us for availability and pricing. |
| SVC-P-SH-S |
Premium Support with guaranteed response and remedy times for regional business hours support Mo-Fr. See your sales rep for details. Annual Subscription up to 1,000 units deployed. |
Contact us for availability and pricing. |
| SVC-ENHWAR1 |
1 Year Enhanced Warranty |
Contact us for availability and pricing. |
| SVC-ENHWAR2 |
2 Year Enhanced Warranty |
Contact us for availability and pricing. |
| SVC-ENHWAR3 |
3 Year Enhanced Warranty |
Contact us for availability and pricing. |
| SVC-ENHWAR4 |
4 Year Enhanced Warranty |
Contact us for availability and pricing. |
| SVC-ENHWAR5 |
5 Year Enhanced Warranty |
Contact us for availability and pricing. |
| SVC-EXTWAR2 |
2 Year Extended Warranty |
Contact us for availability and pricing. |
| SVC-EXTWAR3 |
3 Year Extended Warranty |
Contact us for availability and pricing. |
| SVC-EXTWAR4 |
4 Year Extended Warranty |
Contact us for availability and pricing. |
| SVC-EXTWAR5 |
5 Year Extended Warranty |
Contact us for availability and pricing. |
| SVC-TECH-HOUR |
Network technician hour rate for Pre-config services, after hours support etc? |
Contact us for availability and pricing. |
|
|
