Features
- Ethernet Extension— Extend 10/100Base-TX Ethernet well beyond its 328-foot (100-meter) limitation over a single unshielded twisted pair (UTP) or Cat 5e/6/7 cable.
- Ruggedized—Operating temperature of -40 to 85°C and optional conformal coating to protect against condensing humidity.
- Plug and Play—Set these units up straight out of the box. No configuration is required. Auto-sensing 10/100 Ethernet ports support full or half duplex operation.
- Transparent LAN Bridging—Bypass network configuration requirements by transparently passing all higher layer protocols—including 802.1Q VLAN frames (tagged and untagged). Data-transmission mechanism is fully transparent to such IP video compression schemes as MPEG-4, H.264 and MJPEG.
- Flexible Installation—Wall-mount ready and an optional DIN rail mounting kit is available.
- Multiple Line Rates Supported—Switch-selectable rate mode options optimize rate and reach for the noise environment, wire gauge/type and length.
- Made in the USA — This Patton equipment is designed by Patton engineers and built in our Gaithersburg, Maryland facility. Patton's American-made manufacturing process delivers high-quality networking solutions with reliability you can trust.
Overview
Perfect for bandwidth-intensive applications the CopperLink™ 1214E delivers off-the-chart symmetrical line rates greater than 168 Mbps. Best of all—like all CopperLink™ products—the CL1214E leverages existing copper infrastructure to deliver high speed Ethernet connectivity over single twisted-pair or Cat 5e/6/7 cable.
Four user-selectable configuration profiles—combined with Patton’s auto-rate adaptation feature—ensure maximum achievable symmetrical or asymmetrical rates for the installed noise environment, wire gauge/type and length.
Symmetrical line-rate settings are ideal for such applications as remote LAN extension, video teleconferencing, and data backhaul.
Asymmetrical configurations are well-suited for applications requiring higher downstream speeds and/or longer distances between Ethernet devices. Typical asymmetrical scenarios include medical imaging, livestock monitoring, underwater video, internet gaming, and transporting high-resolution IP video from security cameras.
Realize fiber-like speed and distance without the expense of fiber with Patton’s Ultra-High-Speed CopperLink™ Ethernet Extenders.
Applications
Typical Application
A built-in 4-port Ethernet switch makes the CopperLink 1214E ideal for delivering multiple IP information streams over a single cable. For example, at a guardhouse or security kiosk, you could aggregate IP data from a laptop, a motion sensor, and two high resolution IP video cameras for simultaneous transmission over a single Ethernet connection.
Combining data flows from up to four network-enabled devices onto a single twisted pair, the Model 1214E can deliver IP traffic up to 1.8 miles (3 km) away—well beyond the standard 328-foot (100-meter) Ethernet distance limitation.
With achievable line rates up to 168 Mbps, the CopperLink 1214E eliminates the bandwidth constraints commonly experienced with other copper-based transmission technologies. The Model 1214E is engineered to re-use existing infrastructure previously employed in legacy applications including alarm circuits, E1/T1 circuits, RS-232, RS-422, RS-485, CCTV and CATV. Many newer cabling standards are also supported, including Cat 5e, Cat 6, and Cat 7.
Ordering
| # |
Model # |
Description |
Availability |
| 1 |
CL1214E/12 |
Extended Temperature CopperLink High Speed Auto Rate Extender; RJ45 Connector; -12VDC Input |
General Availability |
| |
 Accessories |
| Additional Charge: |
| INS/A-DIN-35 |
DIN Rail Installation Kit; 35MM |
|
| 2 |
CL1214E/BNC/EUI |
Extended Temperature CopperLink High Speed Auto Rate Extender; BNC Connector; 100-240VAC |
General Availability |
| |
| Accessories |
| 12-131 |
United Kingdom plug for interchangeable power supplies |
| 12-132 |
Australian plug for interchangeable power supplies |
| 12-201 |
CON,POWER,SYS-1357,KR |
| 12-202 |
South African plug for interchangeable power supplies |
| Additional Charge: |
| INS/A-DIN-35 |
DIN Rail Installation Kit; 35MM |
|
| 3 |
CL1214E/BNC/EUI-2PK |
Extended Temperature CopperLink High Speed Auto Rate Extender Kit; BNC Connector; 100-240VAC |
General Availability |
| |
| Accessories |
| 12-131 |
United Kingdom plug for interchangeable power supplies |
| 12-132 |
Australian plug for interchangeable power supplies |
| 12-201 |
CON,POWER,SYS-1357,KR |
| 12-202 |
South African plug for interchangeable power supplies |
| Additional Charge: |
| INS/A-DIN-35 |
DIN Rail Installation Kit; 35MM |
|
| 4 |
CL1214E/CC/12 |
Extended Temperature CopperLink High Speed Auto Rate Extender;Conformal Coated; RJ45 Connector; -12VDC Input |
General Availability |
| |
| Accessories |
| Additional Charge: |
| INS/A-DIN-35 |
DIN Rail Installation Kit; 35MM |
|
| 5 |
CL1214E/CC/EUI |
Extended Temperature CopperLink High Speed Auto Rate Extender; Conformal Coated; RJ45 Connector; 100-240VAC |
General Availability |
| |
| Accessories |
| 12-131 |
United Kingdom plug for interchangeable power supplies |
| 12-132 |
Australian plug for interchangeable power supplies |
| 12-201 |
CON,POWER,SYS-1357,KR |
| 12-202 |
South African plug for interchangeable power supplies |
| Additional Charge: |
| INS/A-DIN-35 |
DIN Rail Installation Kit; 35MM |
|
| 6 |
CL1214E/CC/TB/12 |
Extended Temperature CopperLink High Speed Auto Rate Extender; Conformal Coated; Terminal Block Connector; -12VDC Input |
General Availability |
| |
| Accessories |
| Additional Charge: |
| INS/A-DIN-35 |
DIN Rail Installation Kit; 35MM |
|
| 7 |
CL1214E/CC/TB/EUI |
Extended Temperature CopperLink High Speed Auto Rate Extender; Conformal Coated; Terminal Block Connector; 100-240VAC |
General Availability |
| |
| Accessories |
| 12-131 |
United Kingdom plug for interchangeable power supplies |
| 12-132 |
Australian plug for interchangeable power supplies |
| 12-201 |
CON,POWER,SYS-1357,KR |
| 12-202 |
South African plug for interchangeable power supplies |
| Additional Charge: |
| INS/A-DIN-35 |
DIN Rail Installation Kit; 35MM |
|
| 8 |
CL1214E/EUI |
Extended Temperature CopperLink High Speed Auto Rate Extender; RJ45 Connector; 100-240VAC |
General Availability |
| |
| Accessories |
| 12-131 |
United Kingdom plug for interchangeable power supplies |
| 12-132 |
Australian plug for interchangeable power supplies |
| 12-201 |
CON,POWER,SYS-1357,KR |
| 12-202 |
South African plug for interchangeable power supplies |
| Additional Charge: |
| INS/A-DIN-35 |
DIN Rail Installation Kit; 35MM |
|
| 9 |
CL1214E/TB/12 |
Extended Temperature CopperLink High Speed Auto Rate Extender; Terminal Block Connector; -12VDC Input |
General Availability |
| |
| Accessories |
| Additional Charge: |
| INS/A-DIN-35 |
DIN Rail Installation Kit; 35MM |
|
| 10 |
CL1214E/TB/EUI |
Extended Temperature CopperLink High Speed Auto Rate Extender; Terminal Block Connector; 100-240VAC |
General Availability |
| |
| Accessories |
| 12-131 |
United Kingdom plug for interchangeable power supplies |
| 12-132 |
Australian plug for interchangeable power supplies |
| 12-201 |
CON,POWER,SYS-1357,KR |
| 12-202 |
South African plug for interchangeable power supplies |
| Additional Charge: |
| INS/A-DIN-35 |
DIN Rail Installation Kit; 35MM |
|
|
- Ethernet Extension— Extend 10/100Base-TX Ethernet well beyond its 328-foot (100-meter) limitation over a single unshielded twisted pair (UTP) or Cat 5e/6/7 cable.
- Ruggedized—Operating temperature of -40 to 85°C and optional conformal coating to protect against condensing humidity.
- Plug and Play—Set these units up straight out of the box. No configuration is required. Auto-sensing 10/100 Ethernet ports support full or half duplex operation.
- Transparent LAN Bridging—Bypass network configuration requirements by transparently passing all higher layer protocols—including 802.1Q VLAN frames (tagged and untagged). Data-transmission mechanism is fully transparent to such IP video compression schemes as MPEG-4, H.264 and MJPEG.
- Flexible Installation—Wall-mount ready and an optional DIN rail mounting kit is available.
- Multiple Line Rates Supported—Switch-selectable rate mode options optimize rate and reach for the noise environment, wire gauge/type and length.
- Made in the USA — This Patton equipment is designed by Patton engineers and built in our Gaithersburg, Maryland facility. Patton's American-made manufacturing process delivers high-quality networking solutions with reliability you can trust.
Perfect for bandwidth-intensive applications the CopperLink™ 1214E delivers off-the-chart symmetrical line rates greater than 168 Mbps. Best of all—like all CopperLink™ products—the CL1214E leverages existing copper infrastructure to deliver high speed Ethernet connectivity over single twisted-pair or Cat 5e/6/7 cable.
Four user-selectable configuration profiles—combined with Patton’s auto-rate adaptation feature—ensure maximum achievable symmetrical or asymmetrical rates for the installed noise environment, wire gauge/type and length.
Symmetrical line-rate settings are ideal for such applications as remote LAN extension, video teleconferencing, and data backhaul.
Asymmetrical configurations are well-suited for applications requiring higher downstream speeds and/or longer distances between Ethernet devices. Typical asymmetrical scenarios include medical imaging, livestock monitoring, underwater video, internet gaming, and transporting high-resolution IP video from security cameras.
Realize fiber-like speed and distance without the expense of fiber with Patton’s Ultra-High-Speed CopperLink™ Ethernet Extenders.
Typical Application
A built-in 4-port Ethernet switch makes the CopperLink 1214E ideal for delivering multiple IP information streams over a single cable. For example, at a guardhouse or security kiosk, you could aggregate IP data from a laptop, a motion sensor, and two high resolution IP video cameras for simultaneous transmission over a single Ethernet connection.
Combining data flows from up to four network-enabled devices onto a single twisted pair, the Model 1214E can deliver IP traffic up to 1.8 miles (3 km) away—well beyond the standard 328-foot (100-meter) Ethernet distance limitation.
With achievable line rates up to 168 Mbps, the CopperLink 1214E eliminates the bandwidth constraints commonly experienced with other copper-based transmission technologies. The Model 1214E is engineered to re-use existing infrastructure previously employed in legacy applications including alarm circuits, E1/T1 circuits, RS-232, RS-422, RS-485, CCTV and CATV. Many newer cabling standards are also supported, including Cat 5e, Cat 6, and Cat 7.
