What is Power over Ethernet? Power over Ethernet (PoE) is a networking technology that uses a network cable (CAT5, common copper phone wire, or similar) to deliver electrical power to remote endpoint devices. Common endpoints for PoE solutions include VoIP phones, IP cameras, wireless access points (WAP).

A Power-over-Ethernet extender or PoE extender takes PoE technology to the next level by breaking two important boundaries:

1) A PoE Extender can extend the 100-meter distance limitation for standard Ethernet and up to 3,300 feet.

2) A PoE Extender can leverage existing copper twisted-pair cabling to deliver electrical power over the same network connection as the Ethernet data stream.

The advantages of PoE extension include time and cost savings and greater flexibility of endpoint positioning among others.

Order the Free Publication: Ethernet Extenders Product Guide


Show Me: Ethernet PoE Extender : Power Over Ethernet Extender Products




Weather Resistant Ethernet Extender

CopperLink 1101E/IP67 - Weather Resistant Ethernet PoE Extender & Power over Ethernet extender
CopperLink 1101E/IP67
IP67 Rated (Designed to NEMA 4X) Industrial Grade Power-over-Ethernet (PoE) Ethernet Extender. PowerPlus technology powers up both the remote CopperLink extender and the PoE enabled device connected to it. No power is required at the remote location.

Industrial Grade PoE Ethernet Extenderr

CopperLink 1101E - Industrial Grade Ethernet PoE Extender
CopperLink 1101E
Extend Ethernet & Power over Ethernet (PoE) using existing twisted pair(s) or coax. Benefit instantly from the power and flexibility of IP without downtime or infrastructure and installation expenses!

Ethernet Booster

CopperLink 2110 - Ethernet Booster & Power over Ethernet Extender
CopperLink 2110
Offers PoE Injector, Ethernet Extender, and PoE Ethernet repeater options. Doubles Ethernet and PoE distances over existing copper wire.

Ethernet & PoE Surge Protectors

Connect-IT 570-POE - Ethernet PoE Extender & PoE Surge Protectors
Connect-IT 570-POE
Twisted-pair surge protectors are EIA/TIA TSB-40A Cat 5 certified, and operate at speeds up to 100 Mhz. These units protect 100Base-TX data lines without hindering network performance.


Teach Me: More about PoE Extender Solutions


Electricity operates at a frequency of 60 Hz or less, while data transmission operates within frequencies between 10 million to 100 million Hz. By taking advantage of the frequency separation between electrical power transmission and digital data streams, both services can be delivered over the same cable using a PoE extension product, i.e. a PoE Extender. IEEE specification 802.3af provides for up to 5 watts of electrical power while IEEE 802.3at (PoE plus) provides up to 25 watts.

Demand for IP/Ethernet-connected devices is soaring with global expansion of the Internet of Things (IoT). Because it strikes the perfect blend of speed, cost, and ease of use, the popularity of power-over-Ethernet (PoE) is escalating.

PoE solutions can breathe new life into circuits previously deployed for such traditional non-IP applications as RS232/485 HVAC and building automation controls, alarms, CCTV, analog phones, intercom speakers, and others.

Typical Application for Power over Ethernet Extension



With the extended reach Patton PoE products provide, you can install your IP equipment exactly where you want it! Flexibility of device location is paramount in such applications as building security, where increased perimeter dimension and expanded spot coverage area are critical. Now you can quickly install PoE-capable devices such as wireless access points (WAPs), IP cameras, IP telephones, IP door stations, HVAC controls, LED lighting and more-with no additional overhead cost.


Help Me: PoE Extender Technical Help


Patton offers an extensive online library of technical information to help you get your CopperLink PoE Ethernet Extender up and running quickly and easily. Patton's web-based FAQs, configuration notes, and application notes provide the detailed knowledge you need to install, configure, troubleshoot and maintain your Patton PoE device. These helpful resources are all free right here on www.patton.com. Patton stands behind our high-quality PoE products-world-renowned for set-it-forget-it reliability and stability-with live email and phone support plus lifetime downloadable software updates absolutely free of charge.



LAN/Ethernet Port Protectors
Connect-IT, 520
Flexible Surge Protectors with Terminal Strips
Connect-IT, 570
10/100/1000 Ethernet Port Protectors
Connect-IT, 570R
10/100/1000 Base-T Multi-Port Surge Protectors (8 & 16 Ports)
PoE + Ethernet Extenders
CopperLink, CL1100
Power over Ethernet (PoE) Ethernet Extender | up to 3300 ft/1005 meters
CopperLink, CL1100E
Industrial Grade Power-over-Ethernet (PoE) Ethernet Extender | up to 3300 ft/1005 meters
CopperLink, CL1101E67
IP67 Rated/NEMA 4X Industrial Grade Power-over-Ethernet (PoE) Ethernet Extender
CopperLink, CL1151E
Dante over Copper 10/100 Extender
