What is Ethernet? Ethernet is a data-transmission protocol for computing devices connected by a local area network. The technology specifies physical-layer cabling as well the format of digital data protocol data units (PDUs). A key feature of Ethernet technology is the technique known as carrier sense multiple access with collision detection (CSMA/CD), which allows multiple device to share a communication channel over a single medium such as CAT5e.

What is Ethernet extension? Standard Ethernet specifies a maximum distance of 100 meters (328 feet) using CAT5 or higher grade cable. Ethernet extension technology provides two functions: 1) extending the distance of an Ethernet connection far beyond the standard 100-meter distance limitation, and 2) expanding the cabling options to include a wider array of physical media, such as unshielded twisted pair (UTP) or coaxial, as well as CATx cabling. The technology involves installing a pair of devices, one at each end of the link, to convert the data stream to an encoded signal that can be carried over a longer distance.

Order the Free Publication: CopperLink™ Product Guide




Show Me: Ethernet Extenders - Ethernet Cable Extender and Ethernet extension solutions)




Managed Ethernet Extender

CopperLink 2300 - Managed Ethernet Extender (Ethernet Cable Extender)
CopperLink 2300
The CopperLink 2300 offers the best bandwidth and distance combination in the CopperLink product line. Speeds in excess of 22.8 Mbps symmetrical at distances of 2 miles (3.2 km) are possible due to Patton's pair bonding which supports up to 4 individual twisted-pairs (8-wire) or just a single Cat 5 or higher rated cable.

Ultra-High-Speed Copper Ethernet Extender

CopperLink 1214 - Ultra-High-Speed Copper Ethernet Extender
CopperLink 1214
Achieving downstream line rates up to 168 Mbps over single twisted-pair, Cat 5e/6/7 or coaxial cable, Patton's CopperLink™ Model 1214 Ultra-High-Speed Ethernet Extender is the fastest CopperLink™ ever.

Ruggedized Multi-Drop Ethernet Extender

CopperLink 1314MDE - Ruggedized Multi-Drop Ethernet Extension Solution
CopperLink 1314MDE
Use the CopperLink 1314MDE Multi-Drop Ethernet Extender to interconnect and daisy chain multiple remote networks and network enabled devices up to 6 miles (10 km) or more apart using single-twisted-pair cabling.

PoE Ethernet Extender

CopperLink 1101 - PoE Ethernet Extender & Ethernet Cable Extender for Ethernet Extension
CopperLink 1101
Energize your existing cable plant today with Patton's new CL1101 PoE Extender. A pair of CL1101 units will enable 10 or 100Mbps of Ethernet & Power over Ethernet (PoE/PoE+) to be passed over your existing twisted pair(s) or coaxial cables. Realize the many benefits of Ethernet with little to no downtime, construction or infrastructure related expenses!


Teach Me: All About Ethernet Extenders: Ethernet Cable Extender, Ethernet Extension, Ethernet Repeaters & Ethernet Booster Products


Ethernet extenders allow network designers to extend Ethernet connections well beyond the standard 328-foot (100-meter) Ethernet distance limitations. AKA Ethernet Repeaters, the devices can establish long-range, high-speed data communication links between geographically separated LANs or LAN devices. Ethernet extension products are often employed to connect workgroups on different floors within a building.

Common Ethernet Extender Applications

drawing show Ethernet extedners / Ethernet repeaters / Ethernet booster application


Benefits of Ethernet Extension Technology
An Ethernet extension device can eliminate the need for expensive Ethernet switches and Cat 5 cable by using fiber-optic or copper twisted-pair cables to transparently send packets at full line rates to a peered LAN up to 5 miles (8 km) away. IT managers typically deploy the device within a limited geographical area. Yet this area need not be limited to one building. Sometimes called an Ethernet Booster, the unit can create reliable bridged-Ethernet connections across streets or over a college or enterprise campus and between Ethernet LANs up to 5 miles (8 km) apart.

An Ethernet range extender is a cost-effective alternative to more complicated and pricey wiring choices like Cat 5 cable. Because they are plug-and-play networking devices, they are fast and easy to install. Taking advantage of existing copper twisted-pair network infrastructure, and depending on the required data rate, An Ethernet extender may increase the distance of an Ethernet link up to 5 miles (8 km) and beyond.


Help Me: Ethernet Extension Technical Help


Patton offers an extensive online library of technical information to help you get your CopperLink product up and running in a jiffy. Patton's web-based FAQs, technical notes, and user manuals provide the detailed knowledge you need to install, configure, troubleshoot, and maintain your Patton CopperLink unit. And these helpful resources are all free on www.patton.com. Patton stands behind our high-quality CopperLink products—world-renowned for set-it-forget-it reliability and stability-with live email and phone support plus lifetime downloadable software updates absolutely free of charge.



High Speed Ethernet Extenders
CopperLink, CL1100
Power over Ethernet (PoE) Ethernet Extender | up to 3300 ft/1005 meters
CopperLink, CL1100E
Industrial Grade Power-over-Ethernet (PoE) Ethernet Extender | up to 3300 ft/1005 meters
CopperLink, CL1151E
Dante over Copper 10/100 Extender
CopperLink, CL1212
Ultra-High-Speed Copper Ethernet Extender | 168 Mbps Downstream
CopperLink, CL1212E
Industrial Grade Ultra-High-Speed Copper Ethernet Extender | 168 Mbps Downstream
CopperLink, CL1214
Ultra-High-Speed Multi-Port Copper Ethernet Extender | 168 Mbps Downstream
CopperLink, CL1214E
Industrial Grade High-Speed Copper Multi-Port Ethernet Extender | 168 Mbps Downstream
CopperLink, CL-SFP
Copperlink SFP Module, Long Range, High Speed, Single Pair, GigE Ethernet Extender SFP
Long Range Ethernet Extenders
CopperLink, CL1314
Long Range Ethernet Extender | up to 6 miles (10 km) over copper
CopperLink, CL1314R
Industrial Grade, Long Range Ethernet Extender | up to 6 miles (10 km) over copper
CopperLink, CL1314MDE
Ruggedized Multi-Drop Ethernet Extender & Repeater | up to 6 miles (10 km) over copper
CopperLink, CL2300
Long Range-Bonding Wire-Bonding Ethernet Extender | up to 6 miles (10 km) over copper
CopperLink, CL2300E
Industrial Grade, Long Range-Bonding Wire-Bonding Ethernet Extender | up to 6 miles (10 km) over copper
CopperLink, CL2320R
Long Range Ethernet and RS-232 Extender | up to 4 miles (6.5 km) over copper
CopperLink , CL2380R
Long Range Hybrid Copper-Fiber Ethernet Extender
CopperLink, CL-SFP
Copperlink SFP Module, Long Range, High Speed, Single Pair, GigE Ethernet Extender SFP
PoE + Ethernet Extenders
CopperLink, CL1100
Power over Ethernet (PoE) Ethernet Extender | up to 3300 ft/1005 meters
CopperLink, CL1100E
Industrial Grade Power-over-Ethernet (PoE) Ethernet Extender | up to 3300 ft/1005 meters
CopperLink, CL1101E67
IP67 Rated/NEMA 4X Industrial Grade Power-over-Ethernet (PoE) Ethernet Extender
CopperLink, CL1151E
Dante over Copper 10/100 Extender

Ethernet Isolators / Converters / Modems
FiberPlex, FOI-1GBT
Ethernet-to-Fiber Converter | 1000BASE-T Isolator/Modem enclosed in mission critical packaging
FiberPlex, FOI-4110
Fiber Optic Isolator/Converter/Modem - 10/100BASE-T Ethernet; mission critical packaging
Industrial Copper/Fiber/SFP Ethernet Switches
FiberPlex, FP1004E
Un-Managed Industrial Gigabit Ethernet Switch 6 Port 10/100/1000, 4 Copper + 2 x GigE SFP; industrial TD packaging
FiberPlex, FP1008E
Un-Managed Industrial Gigabit Ethernet Switch 10 Port 10/100/1000, 8 Copper + 2 x GigE SFP; industrial packaging
FiberPlex, FP1108E
Un-Managed Industrial 10 Gig Ethernet Switch 10 Port, 8 Copper 10/100/1000 + 2 x 10 GigE SFP; industrial packaging
FiberPlex, FP2008E
Managed Industrial Gigabit Ethernet Switch 10 Port, 8 Copper 10/100/1000 + 2 x GigE SFP; industrial packaging
FiberPlex, FP2008EAT
Managed Industrial Gigabit PoE+ Switch 10 Port, 8 Copper 10/100/1000 + 2 x GigE SFP; industrial packaging
FiberPlex, FP1008EAT
Un-Managed Industrial Gigabit PoE+ Switch 10 Port, 8 Copper 10/100/1000 + 2 x GigE SFP; industrial packaging
FiberPlex, FP2024E
Ruggedized (IP30), POE & SFP 28-Port Industrial Gigabit Managed Ethernet Switch
FiberPlex, FP2124R
Ruggedized 24-SFP-Port Industrial GigE and 10Gig Managed Ethernet Switch
CopperLink , CL2380R
Long Range Hybrid Copper-Fiber Ethernet Extender
Ethernet Over Fiber Extender Kits (2-Pack)
FiberPlex, TKIT-ETH
LAN to Fiber Converter | Ethernet to Fiber Optic Conversion Kit
