FiberPlex FP102E Industrial 10 Gigabit Media Converter

Overview
Patton’s FP102E converts singlemode or multimode fiber to a copper Ethernet signal. 10-gigabit Ethernet is ideal for bandwidth intensive audio and video over IP applications like SDVoE or HDBaseT, telecom backhaul, transportation, and data center connectivity.

Because 10-gigabit Ethernet over Cat 6a cables is limited to about 50 meters (164 feet), using fiber as a backhaul allows for a massive increase in distances. SFP options for multimode can reach up to 2 km (1.24 miles) and singlemode options can range as far as 60 km (37 miles). In addition to the reach, you get fiber’s superior immunity to noise and, harmful transients (surges).

The FP102E is housed in an IP30-rated DIN-rail or wall-mount enabled enclosure, and has an operating temperature of -40 to 75°C. Its rugged design and wide temperature range makes it an ideal media converter for industrial or harsh environments.

The Fiberplex FP102E is very simple to use, completely plug and play. LEDs will make it clear when power is detected, data is being passed on both the fiber and copper links and what data rates are being detected.

Applications

Features

• Extended Operating Temperature - -40 to 75°C (-40 to -167°F) ambient temperature range.
• Flexible Mounting Options - Wall mount, DIN rail or desktop.
• Rugged - Meets tough EN60068 standards for Free Fall, Shock and Vibration.
• Plug and Play - Auto sensing network speeds and PoE compliant power negotiation makes this product incredibly easy to use.
• TAA Compliant - Top notch quality and reliability with local support.

Ordering

# Model # Description Availability 1 FP102E/SFP/DC Industsrial 10 Gigabit SFP Media Converter; 1G/10GBase-T (RJ45); 1G/10GBase-X (SFP); -40 ot 75C; 12-56VDC Input Pre-Order Available    Accessories Additional Charge: Power Supply 25000044   (Qty: 1) Industrial AC/DC DIN Rail 150Watt Power Supply, HDR-150-48, 48VDC/3.2A output, 85-264VAC input; -30 to 70C 25000045   (Qty: 1) Industrial AC/DC DIN Rail 60 Watt Power Supply, HDR-60-48, 48VDC/1.25A output, 85-264VAC input; -30 to 70C SFP SFP-MC92XC-3131-1 SFP, Optical Multimode LC, 10GB (OC192), Data Transceiver, TX:1310 nm RX:1310 nm, < 2km, MSA SFP-SC92CW-3131-A SFP, Optical Singlemode LC, 10GB (OC192), Data, CWDM Transceiver, TX Wavelength:1310 nm , RX Wavelength:1310 nm, 10km, MSA
