CopperLink CL241EBT Industrial Gigabit 15-90W PoE Splitter



CopperLink CL241E industrial 90W Gigabit PoE splitters allow non-PoE-enabled devices to operate with PoE. The splitter can be adjusted for use with 12, 16, 24, or 48-VDC devices.


Overview
Patton’s CL241E is the only PoE splitter you will ever need. This Industrial PoE splitter can accept PoE power from 15W (802.3af) up to 90W (latest standard of 802.3bt). This splitter is even backward-compatible with 95W PoH and 60W uPoE standards.

The splitter takes the power delivered from the PoE of the Ethernet port and splits it onto a terminal block interface. The outgoing Ethernet port now has only Ethernet data, and the non-PoE devices can be powered at a wide variety of DC voltage levels from the terminal block.

This is a perfect PoE splitter for use in light industrial environments. The CL241E is housed in an IP30 rated DIN rail, wall-mount enabled enclosure and has a wide operating temperature of –40 to 167°F (40 to 75°C).

Its rugged design, wide temperature and power input range makes it an ideal model for security, building automation, transportation and telco applications.

The CL241E is very simple to use. All networking parameters are auto-detected. The only configuration required is to determine what voltage will be delivered to your non PoE enabled units, this configuration is made via a pair of DIP switches. LEDs will make it clear when PoE is being delivered and when DC voltage is being applied.

Applications

CopperLink™ CL241E application diagram


Features
  • Extended Operating Temperature - 40 to 167F (-40 to 75C) ambient temperature range
  • Flexible Mounting Options - Wall mount, DIN rail or desktop.
  • Rugged - Meets tough EN60068 standards for Free Fall, Shock and Vibration.
  • Wide Range Dual Power Output - Two power outputs that DC voltage options of 48, 24, 16 or 12 VDC @1.5A.
  • Plug and Play - Auto-sensing network speeds and PoE compliant power negotiation makes this product incredibly easy to use.
  • TAA Compliant - Top notch quality and reliability with local support.

Ordering
# Model # Description Availability
1 CL241E/BT90/DC Industrial Gigabit 15-90W PoE Splitter; Output 12/16/24/48VDC Pre-Order Available
