Features
- Switched-56 and All Rate Dedicated Operation
- Asynchronous Operation
- Half or Full Duplex over 2 or 4 wire lines
- Maximum cable length 4000 ft.
- Supports Data rates to 115.2 kbps
- 2500 Vrms isolation
- Made in the USA — This Patton equipment is designed by Patton engineers and built in our Gaithersburg, Maryland facility. Patton's American-made manufacturing process delivers high-quality networking solutions with reliability you can trust.
Overview
The 593 is available in three versions: RS-422, DB-25, and Terminal Block. The 593 Series connects any RS-422 or RS-485 equipment and isolates RS-485 and RS-422 signals.
All Models have selectable Dip switch settings for RS-422/RS-485 applications. The Model 593 Series provides 2500Vrms of isolation and supports data rates up to 115.2 kbps. The Models 593/25F/45/TB are powered by an external +5V regulated power supply.
The Models 593/25F, 593/45, and 593/TB isolates transmit data (XMT+ and XMT-) and receive data (RCV+ and RCV-). The Model 593/45 has a RJ-45 on both sides, the Model 593/TB has a terminal block on both sides, and the Model 593/25F has DB-25 female connectors on both sides.
Ordering
| # |
Model # |
Description |
Availability |
| 1 |
593/25F/UI |
RS-422/485 DB25 OPTICAL ISOLATOR, 120-220 VAC |
End of Life-Notice |
| |
 Accessories |
| 12-201 |
CON,POWER,SYS-1357,KR |
| 12-202 |
South African plug for interchangeable power supplies |
|
| 2 |
593/45/UI |
RS-422/485 RJ45 OPTICAL ISOLATOR, 120-220 VAC |
End of Life-Notice |
| |
| Accessories |
| 12-201 |
CON,POWER,SYS-1357,KR |
| 12-202 |
South African plug for interchangeable power supplies |
|
| 3 |
593/TB/UI |
RS-422/485 TERMINAL BLOCK OPTICAL ISOLATOR, 120-220 VAC |
End of Life-Notice |
| |
| Accessories |
| 12-201 |
CON,POWER,SYS-1357,KR |
| 12-202 |
South African plug for interchangeable power supplies |
|
|
- Switched-56 and All Rate Dedicated Operation
- Asynchronous Operation
- Half or Full Duplex over 2 or 4 wire lines
- Maximum cable length 4000 ft.
- Supports Data rates to 115.2 kbps
- 2500 Vrms isolation
- Made in the USA — This Patton equipment is designed by Patton engineers and built in our Gaithersburg, Maryland facility. Patton's American-made manufacturing process delivers high-quality networking solutions with reliability you can trust.
The 593 is available in three versions: RS-422, DB-25, and Terminal Block. The 593 Series connects any RS-422 or RS-485 equipment and isolates RS-485 and RS-422 signals.
All Models have selectable Dip switch settings for RS-422/RS-485 applications. The Model 593 Series provides 2500Vrms of isolation and supports data rates up to 115.2 kbps. The Models 593/25F/45/TB are powered by an external +5V regulated power supply.
The Models 593/25F, 593/45, and 593/TB isolates transmit data (XMT+ and XMT-) and receive data (RCV+ and RCV-). The Model 593/45 has a RJ-45 on both sides, the Model 593/TB has a terminal block on both sides, and the Model 593/25F has DB-25 female connectors on both sides.
