Very-Low-Cost Session Border Controller 3CX for SoHo and SME

Overview

This SIP SBC is designed to resolve the complex security, interoperability, and service-quality issues service providers and enterprises face. Patton’s very-low-cost SmartNode™ SN500 eSBC is perfect for delivering high-quality SIP trunk, hosted PBX and UC services for SOHOs and SMEs, especially in Session Border Controller 3CX implementations.

Service providers do not typically own the transport network, so they cannot control the quality of service at the customer premise. That’s where the eSBC comes in:

The SN500 is operated, managed, and administrated by the Patton Cloud, which provides proactive notification of performance issues in the customer network that may impair call quality. Automated alerts allow pre-emptive corrective actions that reduce service downtime and increase customer satisfaction.

Applications

The SN500 is ideal for such applications as SIP trunking and unified communications as as service (UCaaS)—with a cloud/hosted PBX.

SmartNode SN500 Unified Communications as a Service Application

SN500 eSBC SIP Trunk application drawing

SmartNode SN500 SIP Trunking Application

Installed at the SoHo or SME customer premise, the SN500 provides a clear network separation point (demarc) between the subscriber LAN and the service provider WAN.

In conjunction with the Patton Cloud, the eSBC monitors SIP traffic and call quality, and triggers an e-mail or SMS notification whenever call-quality drops.

Remote SIP endpoints (phones, computer terminals, etc.) can be easily provisioned, monitored and managed using the Patton Cloud.

Features

SLA Monitoring - Call Quality monitoring ensures service level agreement (SLA) is met at the customer premise. Call data recording (CDR) includes voice-quality information, call duration, codec, and more. Accessible by Web and API (OSS/BSS integration).
VoIP Security - Network separation with SIP back-2-back user agent, DoS prevention, trust SIP peer, optional signaling encryption (SIP-TLS), intelligent access control list (ACL).
SIP Normalization & Interop - SIP-to-SIP Interworking, normalizes otherwise incompatible vendor-specific SIP implementations. Service demarcation point provides separation between LAN and WAN.
SIP Endpoint Management - Endpoint provisioning and operating tools include discovery and remote-access of SIP endpoints, maintaining VoIP service.
Easy Management & Provisioning - Patton Cloud network edge orchestration. Automated mass-provisioning with HTTPS delivers secure, zero-touch provisioning. Patton’s cloud-based Web Wizard configuration tool combined with software-image campaign-management ensures efficient large-scale deployments. Free Cloud account required for configuration.
Proprietary Software - Proprietary Trinity™ operating system offers added security.

Ordering

All SN500 models include the following Software Features

SIP Registrar up to 3 inbound registrations (beyond 3 requires TSW-REG-S)

IP Routing (ACL, NAPT, VLAN)

Optional at additional charge:
SIP-TLS (TSW-SIP-TLS-S)

more than 3 inbound SIP Registrations (TSW-REG-S)

more than 4 simultaneous SIP-SIP calls (SNSW-1B)

Model #

Description

Availability

SN500/4B/EUI

SmartNode eSBC, 4 SIP Sessions no RTP transcoding (SIP b2b UA) upgradeable (max. 30), 3 inbound SIP Registrations incl., 2x Gig Ethernet, external UI power NA/EU (100–240)

General Availability

Accessories

Additional Charge:
Misc
INS-KIT-1 (Qty: 1)	Conosle EIA-561 RJ45 to DB9 Adapter with 4 foot straight through CAT6 cable
Power Plugs & Cords
12000186 (Qty: 1)	CON,POWER,PLUG,MEGA MJSW, US
12000187 (Qty: 1)	CON,POWER,PLUG,MEGA MJSW,EU
12000188 (Qty: 1)	CON,POWER,PLUG,MEGA MJSW,UK
12000189 (Qty: 1)	CON,POWER,PLUG,MEGA MJSW,AUS
12000239 (Qty: 1)	CON,POWER,PLUG,MEGA MJSW,CHINA
12000240 (Qty: 1)	CON,POWER,PLUG,MEGA MJSW,ARGEN
12000241 (Qty: 1)	CON,POWER,PLUG,MEGA MJSW,KOREA
12000242 (Qty: 1)	CON,POWER,PLUG,MEGA MJSW,INDIA,SA
12000243 (Qty: 1)	CON,POWER,PLUG,MEGA MJSW,BRAZIL
Software License
SNSW-1B	SmartNode License for 1 additional SIP Call (SIP back-to-back calls using 2 SIP Legs)
SVC-INTEG-MST	Professional Services for up to 3hrs of MS Teams integrations support
TSW-MST	Permanent License for Microsoft Teams activation (includes Teams Activation, TLS, unlimited SRTP and Silk passthrough)
TSW-REG-S	License Key for SIP Registrar (unlimited inbound registrations) Small CPE`s (SN500)
TSW-SIP-DNS-FAILOVER	SIP-DNS-SRV-record-based failover service (Trinity only)
TSW-SIP-TLS-S	SIP TLS license for Small CPE`s (SN200, SN500)
TSW-SRTP-CHAN1	SRTP Channel license (For one SIP-SIP call using SRTP. Supported on SN55xx, SN41xx, SN474x, SM56xx, vSN)
