Products  >  SmartNode SN4660  >  SmartNode SN4660 View Printable

This enterprise VoIP Router IP-enables any legacy digital and/or analog voice/fax system for up to 8 to 24 concurrent VoIP /T.38 fax calls. The SN4660 connects ISDN-PBX, analog fax/phonesóeven audio-intercom systemsówith IP telephony and the PSTN.

The SmartNode™ 4660 VoIP Gateway Router offers flexible combinations of ISDN BRI, analog FXS/FXO, and Ethernet/IP interfaces to deliver a unique solution allowing the Enterprise to IP-enable legacy ISDN-PBX and analog phone/fax/answering machine and audio-intercom systems.

Providing 4 Ethernet, 2 to 8 BRIs, up to 4 FXS and up to 4 FXO ports, the SN4660 VoIP Router inter-connects any Ethernet switch, ISDN PBX, analog equipment or IP-data network to support 8 to 24 simultaneous VoIP calls using SIP, FXS/FXO or BRI signaling. The 10/100 Ethernet uplink provides seamless WAN access via any existing cable, ADSL, VDSL, EFM, or fiber-optic modem.

Like every SmartNode™, the SN4660 supports every industry-standard CODEC to deliver toll-quality voice on every call. Adding session border controller capabilities, the SN4660 VoIP Router includes IP transcoding for up to 12 SIP channels. The Unified Communications Agent™ (UCA) provides any-to-any multi-path switching (simultaneous SIP, H.323, ISDN, and POTS calls with routing and conversion between TDM/PSTN and IP/Ethernet networks—plus T.38 and SuperG3 FAX). VoIP-over-VPN with voice encryption provides secure voice and data via IPsec with AES/DES strong encryption and automated keying via Internet Key Exchange (IKE). In addition, advanced call-router functionality includes least-cost call routing with flexible dialed-number plan support.

The SmartNode survivability suite combines PSTN fallback, SIP Registrar and IP-link redundancy to ensure business continuity if the IP network fails. Patton’s DownStreamQoS™ delivers the advantage of clear, uninterrupted voice-and-data communication. Furthermore, SmartNode’s unique high-precision clock delivers first-line IP telephony service in demanding ISDN and DECT environments with reliable FAX and modem performance. In addition, SmartNode delivers a smooth transition to VoIP with strong number portability support accepting incoming calls from the PSTN throughout the VoIP service provider's number porting process.

Preserve investments in legacy phone equipment while taking the next steps toward unified communications with the SN4660 Gateway Router.

Convert Legacy PBX and FAX to VoIP

  • Flexible ISDN BRI and FXS/FXO Port Combinations—VoIP Gateway Router connects analog phone/fax, answering machines, intercom stations, and ISDN-PBX systems with combinations up to 4 FXS, up to 4 FXO, and 2 to 8 BRI interfaces.
  • Proven Interoperability—SIP interop with major IP PBX, softswitch, and VoIP service providers.  Over 100,000 SmartNode deployments worldwide.  ISDN/PSTN compliance in nearly every country.
  • QoS and Security—Deliver secure, toll-quality voice communications with Patton’s DownStreamQoS™ with adaptive traffic management and shaping—plus secure voice-over-VPN with AES/DES strong encryption.
  • Transparent Telephony Features—Complex number manipulation and mapping for seamless integration with existing infrastructures, CLIP, CLIR, hold, transfer and much more.
  • Fax that Works—T.38, SuperG3 Fax, enhanced G.711 fax and modem bypass provide reliable fax over VoIP networks using traditional analog or IP-based fax end stations.
  • High-Precision Clock—Delivers DECT PBX interoperability and reliable fax performance.
  • Supported by SmartNode™ Redirection Service: A free service enabling zero-touch mass deployments for Service Providers and Distributors with auto-provisioning servers (Learn More).

Product Change Notice:
Due to the fast evolvement of VoIP & All-IP technology happening in the market, high performance HW but also Software is required on Customer Premise Equipment. Since the SmartNodes series SN4630; SN4650; SN4660; SN4670 were in the market for many years, its HW capabilities are reaching it`s limits. In parallel, Patton developed new, more state of the art Hardware that is running the latest operation system with the latest features, which is now replacing the SmartNodes series SN4630; SN4650; SN4660; SN4670.
See the Product Change Notice for more details.

Current SKU Replacement Gateway or Replacement eSBC or Replacement eSBC
or Enter Manually



Ordering information for this product is not publicly available at this time.
Please accept our apology as we regret any inconvenience to you.

For more information
about the availability of this product and/or alternative solutions,
please contact Patton's Product Management team at or +1 301 975 1000
